FEATURES
- Ultra Lightweight
- Low friction 2-stage Orbital ball bearing system
- Highest working load in its class
- Low profile and compact
- High performance cleating
- Swivel shackle head for unlimited block rotation.
- Stainless steel shackle head and compatibility with sharp fixing points.
- Ultra low profile integrated beckets.
Holding power 20:1
| Sheave Ø | 55 mm |
|---|---|
| Max. Rope Ø | 10 mm |
| Max. Cable Ø | mm |
| Pin Ø | 5 mm |
| M.W.L. | 750* kg |
| B. L. | 1500 kg |
| Weight | 316 g |
Total block load. Load on becket not to exceed 33% of block load. ie. MWL 250kg (550lb), BL 500kg (1100lb).
